Karlville K2 Seam 300D HS 2014
Seaming machine for shrink labels
Automatic solvent position system with fibber optic edge guide with Web width measurement system without reporting
Maximum speed: 300 m/minute
Width final product: 55 – 300 mm
Shrink PVC, OPS, PET, PLA
Maximum diameter of unwind and rewind roll: 600 mm
Pneumatic shafts of diameter: 76 mm
Side control equipment with ultra-sensor
Tension control using measuring rollers and closed-loop feedback
Unwind tension control – powder brake
Glue tank with level sensor and operator signalization
Inspection system for checking welds (second pass through the machine)
Continuous dual perforation on the unwinder
Second etchant application system (for pocket sleeve)
NORDSON direct injection system
Automatic control of shrink sleeve width
Segment pressure rollers – different sizes
Separate unwinding and winding shaft 3”
Antistatic shaft SUNJE
Nozzle focusing device
Mechanical oscillation system on the winding
Touch display
Perforation wheels – spares
Pressure tongues – spares
